Project Brief Introduction:

1.Product:Wet EFB Pellet Line

2.Capacity: 7.5-9 T/Hour

3.TONY Brand  7.5-9 Ton /Hour Wet EFB Pellet Line Project Process

4.Main Machine:Comprehensive Chipper, Hammer Mill, Rotary Drum Dryer,TONY Pellet Machine TYJ760-Ⅲ-160KW,Pellets Cooler,Packing Machine And Belt Conveyors

5.Total Power: About 1100 kw

6.Need Area: About   ㎡  L:  M  W:  M  H:  M

Project Layout For Customer:

三维图

原材料图+颗粒机图片

1. The working principle of wet EFB biomass pellet processing equipment

(1) Feeding and pre-pressing: The crushed EFB material is fed into the pelletizing chamber by the feeder and evenly distributed to the gap between the pressing roller and the ring die (0.1-0.3mm) through the material plate;

(2) Extrusion heating: The pressing roller is driven by a motor to rotate (speed 200-300r/min), forcing the material into the cylindrical die hole of the ring die - the material is subjected to a huge extrusion pressure (30-100MPa) in the die hole, and at the same time, it produces intense friction with the die hole wall, and the temperature rises to 60-90℃;

(3) Natural bonding: The high temperature softens and melts the lignin (content 15%-20%) in the EFB, forming a natural adhesive that bonds the cellulose and hemicellulose particles together;

(4) Extrusion molding: The bonded material is extruded from the other end of the die hole to form cylindrical pellets with a diameter of 6-8mm and a length of 10-30mm, which are cut into the set length by a cutter and discharged.

2. Characteristics of wet EFB biomass pellet processing equipment

Pelletizing is the core process, and the equipment design revolves around "using the natural bonding of lignin to ensure pellet density":

(1) Ring-type pelletizer: thick-walled ring die + large-diameter pressure roller The ring die is made of double-layer wear-resistant alloy steel (wall thickness 15-20mm, ordinary ring die wall thickness 8-12mm), with high die hole finish (Ra≤1.6μm), which can withstand the severe friction of EFB coarse fibers and has a service life of 300-500 hours (ordinary ring die only 150-200 hours); the pressure roller diameter is increased to 180-220mm (ordinary pressure roller 120-150mm), with a larger contact area and more uniform extrusion force, avoiding local overload and ring die cracking.

(2) Adhesive-free design, relying on frictional heat generation

The equipment precisely controls the gap between the roller and the ring die (0.1-0.3mm) and the rotation speed (200-300r/min), so that the EFB generates a high temperature of 60-90℃ in the die hole, which just softens the lignin (lignin softening point 50-80℃). There is no need to add artificial adhesives such as starch and resin, which not only reduces costs but also avoids the generation of harmful gases (such as formaldehyde) during combustion.

3. Application scenarios of wet EFB biomass pellet processing equipment

(1) Energy: Producing biomass pellet fuel to replace coal for power generation or industrial boilers.

(2) Agriculture: Processing into organic fertilizer pellets to achieve nutrient recycling in palm plantations.

(3) Solid waste treatment: Helping palm oil mills achieve EFB reduction and resource utilization, in line with the "zero-waste agriculture" policy requirements.

2.图片

TONY Brand 7.5-9 Ton/Hour Wet EFB Pellet Manufacturing Plant can take wet EFB as the main raw material. After pretreatment and processing, it is solidified into high - density EFB pellet fuel. This fuel is an ideal substitute for coal and oil and plays a role in energy conservation and emission reduction. At present, it has been widely used in regions rich in EFB resources.

1. Capacity: 7.5-9 Ton/Hour

2. Raw materials: Wet EFB

3. Moisture: Wet type, about 40%.

4. Application: All kinds of EFB materials suitable for pellet production.

Suitable customers: Palm plantation owners or related agricultural enterprises have abundant EFB resources. For example, palm oil mills generate a large amount of EFB waste during the production process. Energy companies, EFB biomass pellets as a clean energy, can be used in industrial heating, power generation and other fields, and have synergy with the existing business of energy companies. Environmental investors, investors with financial strength, technology investors, etc.and other places where EFB raw materials have advantages

5. Finished Pellets Markets: Large power plants, domestic heating, industrial heating, combustion heat, heating systems, boiler rooms, school canteens, foundry heat sources.

3.图片

原材料--成品图

1. Project Name: Wet EFB Pellet Production Line

2. Raw Material: All kinds of wet EFB

3. Moisture Content of Raw Material: 40%

4. Capacity: 7.5-9 tons per hour

5. Process: Crushing Process - Fine Crushing Process - Drying Process - Pelletizing Process - Cooling Process - Packing Process

6. Main Equipment: Comprehensive Chipper -TPC1000 - 90kw, Effective Hammer Mill-TFD95*280-280kw, Rotary Drum Dryer-2.5*24m, TONY Pellet Machine- TYJ760-Ⅲ-160kw, Galvanized Pellets Cooler, Double Packing Machine and Belt Conveyors

4.图片

流程图1

流程图2

5.图片

原材料+颗粒图

颗粒+机器图

三维图长宽

三维图高

5.1图片

带原材料-成品图

1.Wet EFB To Palm Fiber Process:

A.This process is mainly used to grind the EFB into palm fiber with size 25-55mm. The finish palm fiber  size can be adjustable by changing different sizes of screeners and adding flying knives inside the wood chipper.

B.TONY brand comprehensive chipper TPC1000-90kw with 6 flying blades type*1 set

C.Capacity:7-10 Ton/Hour.

Main Parts:

(1)TONY's Comprehensive Chipper.

(2)Feed And Discharge Belt Frequency Control To Prevent Card Material

(3)Hydraulic System Control Can Be Used For Thicker Materials

(4)Electronic Control System Allows The Equipment To Be Used Normally

Contact Tony For More Details With Quotation

5.2图片

高效粉碎机带锯末图

2.Palm Fiber Fine Crushing Process:

A.This process is mainly used to crush 25-55mm palm fiber into 8-14mm palm dust.

B.Capacity:10-12 Ton/Hour.

C.TONY brand effective hammer mill TFD95*280-280kw*1set

Main Parts:

(1)TONY Effective Hammer Mill.

(2)Galvanized Dust Collector.

(3)Sawdust Transportation Fan Blower.

(4)Cyclone With Airlock.

(5)Electrical Cabinets.

5.3图片

烘干机带锯末图

3.Wet Palm Dust Drying Process:

A.This process is mainly used to dry the palm dust  from 40% to 10-15%.

B.Capacity:7.5-9 Ton/Hour.

C.TONY use 1 set of 2.5*24m  rotary drum dryer for this process, TONY hot blast stove is made of firebrick pan, shell with H steel plate as the frame.   There are 3 layers of fire blocking device inside, which can effectively prevent the fire from entering the tumble dryer.Customers can choose to use waste wood, biomass pellets, natural gas, etc. as fuel for the hot air furnace

TONY dryer use spiral tube material, and is not easy to deform.

Unlike other manufacturers with iron plate splicing welding, very easy to deformation.

Main Parts:

(1)TONY's Rotary Drum Dryer Main Body.  (Reducers With Motors and Pips.)

(2)TONY's  Hot Stove.

(3)Fan Blower+Cyclone With Airlock.

5.4图片

颗粒机四件套带 原材料，颗粒图

4.Pelletizing Process:

A.This process is mainly used to to product pellets into φ6-8mm.

B.Capacity:7.5-9Ton/Hour.

C.TONY brand vertical ring die pellet machine TYJ760-Ⅲ-160kw*3 sets

D.Double Screw Cycling Silo is added above the pellet machine, which has the advantages of saving space, saving labor, intelligently controlling the feeding speed, not easy to block the material, and improving production efficiency.

Main Parts:

(1)TONY's new Vertical Ring Die Pellet Machine.

(2)Cyclone And Bags Dust Collectors.

(3)Automatic Lubrication System.

(4)Electrical Cabinets.

You can chose TONY new type SS304 pellet machine

5.5图片

镀锌冷却仓加颗粒图

5.Cooling Process:

A.This process is mainly used to cool pellets from 80-90℃ to 20-30℃

B.Capacity:7.5-9 Ton/Hour.

C.TONY brand galvanized pellets cooler *1 set

Main Parts:

(1)TONY's new Galvanized Pellets Cooler With Vibrating Screen.

(2)Cyclone And Bags Dust Collectors.

(3) Fan Blower.

(4)Connect Pipes.

5.6图片

包装机

6.Packing Process:

A.This process is mainly used to pack pellets into 15-50KG/Bags.

B.Capacity:7.5-9 Ton/Hour.

C.TONY  brand double packing machine*1 set

Main Parts:

(1)TONY  Double Packing Machine.

(2)Sew Machine, Buyer Can Also Choose Hot Seal Machine For Chosen,To Confirm With Tony For The Price Difference.

(3)Bags Transportation Conveyors.

(4)Feeding Inlet Silo.

(5)Electrical Cabinets.

6.图片

客户生产线案例图

7.图片

图 湿EFB+颗粒 颗粒机

EFB Biomass Pellet Project Implementation Process: From Planning to Operation

The implementation cycle of an EFB biomass pellet project typically takes 6-12 months and can be divided into three phases: pre-production preparation, construction and commissioning, and operations management. Each phase has clearly defined key tasks.

1. Preliminary Preparation Phase (2-4 months): Determine project feasibility.

Site Selection: The core principles are "proximity to raw materials + convenient transportation." Priority is given to sites within 10-30 kilometers of a palm oil mill, near national highways or industrial parks (area: 5-10 mu for small and medium-sized lines, 15-20 mu for large lines). These sites must meet environmental impact assessment requirements (away from residential areas and water sources).

2. Construction and Commissioning Phase (3-6 months): Hardware implementation and process optimization.

Plant Construction: Functional areas are divided according to process flow (raw material yard, pretreatment workshop, drying workshop, pelletizing workshop, and finished product warehouse). The raw material yard must be protected from rain (to prevent EFB from rain and humidity). Workshops must be ventilated and dust-proof (install exhaust fans and dust removal equipment).

Equipment Procurement and Installation: Purchase a complete set of equipment based on production capacity (pretreatment: vibrating screen, crusher; drying: hot air furnace + The equipment manufacturer is responsible for installation and commissioning of the following components: drum dryer; crushing: hammer mill; granulation: ring die granulator; cooling: countercurrent cooler; packaging: automatic packaging machine.

Process run-in: During the commissioning period (1-2 months), focus on optimizing parameters (such as drying temperature and granulator speed) to ensure pellet quality meets standards (moisture 10%-15%, density ≥1.1g/cm³, and crushing rate ≤3%). Operator training is also required (2-5 people per line are required to master equipment operation and maintenance and parameter adjustment).

3. Operations Management Phase (Long-Term): Cost Reduction, Efficiency Improvement, and Stable Supply

Raw Material Management: Sign long-term supply agreements with palm oil mills (lock in raw material sources), control raw material transportation radius (≤30 kilometers), and avoid excessive moisture content (store fresh EFB for no more than three days to prevent mold).

Production Management: Implement continuous production to reduce equipment idleness; regularly maintain consumable parts (hammers and ring dies, with a lifespan of 300-500 hours) to minimize downtime; utilize EFB dust as drying fuel (instead of purchased coal, reducing energy costs).

Sales Management: Prioritize developing long-term customers (such as nearby palm oil mills and biomass power plants) and sign annual supply agreements (lock in pricing and sales volume). Domestic and export markets can be accessed through distributors, with emphasis on brand packaging.

8.图片

湿EFB图 颗粒图

Core Advantages

1. Environmentally Friendly and Clean:

SO₂ emissions during combustion are <50mg/m³ and NOₓ emissions are <200mg/m³, significantly lower than coal (SO₂ emissions are approximately 2000mg/m³), and meet EU EN14961 biomass pellet standards.

2. High Calorific Value:

With a low calorific value of approximately 16-18MJ/kg (equivalent to 0.6-0.7kg of standard coal), it can meet the needs of industrial boilers and residential heating.

3. Low Cost:

EFB is palm oil mill waste, making it an extremely low raw material cost (available free in some areas, with only transportation costs required), significantly lower than coal and natural gas.

4. Carbon Sequestration and Emission Reduction:

It is a "carbon-neutral" fuel (the CO₂ absorbed during EFB growth is balanced by the CO₂ released during combustion), helping companies achieve their "dual carbon" goals.
