Project Brief Introduction:

1.Product:Wet EFB Pellet Line

2.Capacity: 4-5 T/Hour

3.TONY Brand 4-5 Ton /Hour Wet EFB Pellet Line Project Process

4.Main Machine:Comprehensive Chipper, Hammer Mill, Rotary Drum Dryer,TONY Pellet Machine TYJ551-Ⅲ-132KW,Pellets Cooler,Packing Machine And Belt Conveyors

5.Total Power: About 620 kw

6.Need Area: About   ㎡  L:  M  W:  M  H:  M

Project Layout For Customer:

三维图

原材料图+颗粒机图片

1. The working principle of wet EFB biomass pellet processing equipment

Palm kernel pelletizing equipment is specialized machinery that transforms palm waste materials (such as palm shells, palm fibers, and palm kernel residue) into high-density biomass pellets.  Its core process involves three key steps: "raw material pretreatment → extrusion molding → cooling and shaping." Through physical compression and temperature control, this equipment transforms loose palm waste materials into pellets with a consistent shape and high calorific value.

2. Characteristics of wet EFB biomass pellet processing equipment

Palm kernel processing equipment features distinct advantages, being highly adaptable to the characteristics of palm kernel raw materials and offering efficient functionality. Firstly, it boasts strong adaptability to raw material processing.  To address the hard shell and long fibers of palm kernels, the equipment uses a crusher to grind the raw material to 4-14mm, and then a dryer adjusts the moisture content to 10-15%, meeting the requirements for pelletizing. Secondly, it features high functional integration, often incorporating a "pre-treatment - pelletizing - cooling - packaging" integrated design.  The ring die pelletizer performs high-pressure pelletizing, followed by seamless integration of cooling and packaging equipment, simplifying the process and improving efficiency. Thirdly, it is environmentally friendly and durable.  It relies primarily on the natural lignin binding of the raw material, reducing the need for additives; key components such as bearing steel and ring dies are highly wear-resistant, lowering maintenance costs and ensuring stable operation.

3. Application scenarios of wet EFB biomass pellet processing equipment

In the industrial filling materials sector, palm kernel granules processed by this equipment can serve as environmentally friendly filling materials for mattresses and sofas (replacing traditional synthetic fiber fillers), or be used in industrial filtration (such as in wastewater treatment). This addresses the large-scale raw material needs of furniture manufacturers and environmental equipment producers. Furthermore, in the agricultural recycling sector, small-scale palm kernel processing equipment can help farmers transform palm waste into bedding material for livestock and poultry (providing moisture absorption, breathability, and odor reduction), enabling on-site resource utilization of agricultural waste, thus meeting the needs of small-scale, decentralized production in rural areas of tropical regions.

2.图片

TONY Brand 4-5 Ton/Hour Wet EFB Pellet Manufacturing Plant can take wet EFB as the main raw material. After pretreatment and processing, it is solidified into high - density EFB pellet fuel. This fuel is an ideal substitute for coal and oil and plays a role in energy conservation and emission reduction. At present, it has been widely used in regions rich in EFB resources.

1. Capacity: 4-5 Ton/Hour

2. Raw materials: Wet EFB

3. Moisture: Wet type, about 40%.

4. Application: All kinds of EFB materials suitable for pellet production.

Suitable customers: Palm plantation owners or related agricultural enterprises have abundant EFB resources. For example, palm oil mills generate a large amount of EFB waste during the production process. Energy companies, EFB biomass pellets as a clean energy, can be used in industrial heating, power generation and other fields, and have synergy with the existing business of energy companies. Environmental investors, investors with financial strength, technology investors, etc.and other places where EFB raw materials have advantages

5. Finished Pellets Markets: Large power plants, domestic heating, industrial heating, combustion heat, heating systems, boiler rooms, school canteens, foundry heat sources.

3.图片

原材料--成品图

1. Project Name: Wet EFB Pellet Production Line

2. Raw Material: All kinds of wet EFB

3. Moisture Content of Raw Material: 40%

4. Capacity: 4-5 tons per hour

5. Process: Crushing Process - Fine Crushing Process - Drying Process - Pelletizing Process - Cooling Process - Packing Process

6. Main Equipment: Comprehensive Chipper -TPC1000 - 90kw, Effective Hammer Mill-TFD75*132-132kw, Rotary Drum Dryer-1.8*20m, TONY Pellet Machine- TYJ551-Ⅲ-132kw, Galvanized Pellets Cooler, Semi-automatic Packing Machine and Belt Conveyors

4.图片

流程图1

流程图2

5.图片

原材料+颗粒图

颗粒+机器图

三维图长宽

三维图高

5.1图片

带原材料-成品图

1.Wet EFB To Palm Fiber Process:

A.This process is mainly used to grind the EFB into palm fiber with size 25-55mm. The finish palm fiber  size can be adjustable by changing different sizes of screeners and adding flying knives inside the wood chipper.

B.TONY brand comprehensive chipper TPC1000-90kw with 6 flying blades type*1 set

C.Capacity:7-10 Ton/Hour.

Main Parts:

(1)TONY's Comprehensive Chipper.

(2)Feed And Discharge Belt Frequency Control To Prevent Card Material

(3)Hydraulic System Control Can Be Used For Thicker Materials

(4)Electronic Control System Allows The Equipment To Be Used Normally

Contact Tony For More Details With Quotation

5.2图片

高效粉碎机带锯末图

2.Palm Fiber Fine Crushing Process:

A.This process is mainly used to crush 25-55mm palm fiber into 8-14mm palm dust.

B.Capacity:4-5 Ton/Hour.

C.TONY brand effective hammer mill TFD75*132-132kw*1set

Main Parts:

(1)TONY Effective Hammer Mill.

(2)Galvanized Dust Collector.

(3)Sawdust Transportation Fan Blower.

(4)Cyclone With Airlock.

(5)Electrical Cabinets.

5.3图片

烘干机带锯末图

3.Wet Palm Dust Drying Process:

A.This process is mainly used to dry the palm dust  from 40% to 10-15%.

B.Capacity:4-5 Ton/Hour.

C.TONY use 1 set of 1.8*20m  rotary drum dryer for this process, TONY hot blast stove is made of firebrick pan, shell with H steel plate as the frame.   There are 3 layers of fire blocking device inside, which can effectively prevent the fire from entering the tumble dryer.Customers can choose to use waste wood, biomass pellets, natural gas, etc. as fuel for the hot air furnace

TONY dryer use spiral tube material, and is not easy to deform.

Unlike other manufacturers with iron plate splicing welding, very easy to deformation.

Main Parts:

(1)TONY's Rotary Drum Dryer Main Body.  (Reducers With Motors and Pips.)

(2)TONY's  Hot Stove.

(3)Fan Blower+Cyclone With Airlock.

5.4图片

颗粒机四件套带 原材料，颗粒图

4.Pelletizing Process:

A.This process is mainly used to to product pellets into φ6-8mm.

B.Capacity:4-5Ton/Hour.

C.TONY brand vertical ring die pellet machine TYJ551-III-132kw*2 sets

D.Double Screw Cycling Silo is added above the pellet machine, which has the advantages of saving space, saving labor, intelligently controlling the feeding speed, not easy to block the material, and improving production efficiency.

Main Parts:

(1)TONY's new Vertical Ring Die Pellet Machine.

(2)Cyclone And Bags Dust Collectors.

(3)Automatic Lubrication System.

(4)Electrical Cabinets.

You can chose TONY new type SS304 pellet machine

5.5图片

镀锌冷却仓加颗粒图

5.Cooling Process:

A.This process is mainly used to cool pellets from 80-90℃ to 20-30℃

B.Capacity:4-5 Ton/Hour.

C.TONY brand galvanized pellets cooler *1 set

Main Parts:

(1)TONY's new Galvanized Pellets Cooler With Vibrating Screen.

(2)Cyclone And Bags Dust Collectors.

(3) Fan Blower.

(4)Connect Pipes.

5.6图片

包装机

6.Packing Process:

A.This process is mainly used to pack pellets into 15-50KG/Bags.

B.Capacity:4-5 Ton/Hour.

C.TONY  brand semi-automatic packing machine*1 set

Main Parts:

(1)TONY Semi-Automatic Packing Machine.

(2)Sew Machine, Buyer Can Also Choose Hot Seal Machine For Chosen,To Confirm With Tony For The Price Difference.

(3)Bags Transportation Conveyors.

(4)Feeding Inlet Silo.

(5)Electrical Cabinets.

6.图片

客户生产线案例图

7.图片

图 湿EFB+颗粒 颗粒机

Raw material basis for EFB biomass pellet processing projects

1. Stable Source and Low Cost: EFB is a core waste product of palm oil processing. Every ton of palm fruit processed produces approximately 0.2-0.25 tons of fresh EFB (60%-75% moisture). The raw material supply is extremely abundant.

2. Procurement Method: Primarily purchased from palm oil mills. In many cases, to avoid contamination from EFB stockpiles, mills will provide EFB for free or at a low price. Mills only cover transportation costs, with a recommended transportation radius of ≤30 kilometers to control costs.

3. Raw Material Characteristics: Contains cellulose (40%-45%), hemicellulose (25%-30%), and lignin (15%-20%). Lignin acts as a natural binder, eliminating the need for artificial binders in pelleting, reducing processing costs.

8.图片

湿EFB图 颗粒图

Ecological Benefits and Expanded Applications: Beyond Fuel, Multifaceted Value Revealed

The advantages of palm kernel pellets extend beyond the energy sector; they offer unique value in horticulture, industry, and other applications:

High Suitability for Horticulture: Made from palm fibers, the pellets are soft and breathable, suitable as a mulch (for moisture retention, nutrient preservation, and weed control) or as a potting mix (mixed with peat moss to improve drainage).  They are naturally antibacterial, resistant to mold, and have a lifespan 3-6 months longer than straw-based substrates.

Excellent Industrial Filling Properties: Palm kernel pellets are elastic and resistant to deformation, making them a suitable alternative to synthetic fibers and foam as filling material for mattresses and sofas.  They are natural, environmentally friendly, breathable, and anti-mite, aligning with the "green consumerism" trend in the home furnishings market. Some specially treated palm kernel pellets can also be used as wastewater treatment filter media, offering strong adsorption capacity and biodegradability, thus preventing secondary pollution.

9.图片

绿色地球+原材料+颗粒图
