Project Brief Introduction:

1.Product:Wet Bamboo Pellet Line

2.Capacity: 15 T/Hour

3.TONY Brand 15 Ton /Hour Wet Bamboo Pellet Line Project Process

4.Main Machine: Comprehensive Chipper,Hammer Mill, Rotary Drum Dryer,TONY Pellet Machine TYJ760-Ⅲ-200KW,Pellets Cooler,Packing Machine And Belt Conveyors

5.Total Power: About 2100 kw

6.Need Area: About   ㎡  L:  M  W:  M  H:  M

Project Layout For Customer:

3D图

1. The working principle of wet bamboo biomass pellet processing equipment

The core logic of processing wet bamboo biomass pellets is "dehydration and conditioning first, followed by compression molding." This requires the coordinated efforts of multiple machines to address the difficulties in processing and looseness caused by bamboo's high fiber content and high moisture content (typically, fresh bamboo has a moisture content of 40%-60%, far exceeding the 10%-15% required for molding). The equipment system can be divided into three modules: "pretreatment unit," "drying unit," and "molding unit."

2. Characteristics of wet bamboo biomass pellet processing equipment

(1) Mobile and energy-saving design: The crushing equipment supports motor and diesel engine drive, with a compact and movable structure, suitable for outdoor operations; the hammer crusher uses a high-pressure fan and a screen to separate qualified materials, reducing energy consumption while improving crushing efficiency.

(2) Efficient transmission and durability: The bamboo pellet machine uses high-precision gear transmission (efficiency of more than 98%), the ring die quick-release design is easy to replace, the main shaft and gears are heat-treated and strengthened, and the service life is extended, which is suitable for the high-pressure pelletizing needs of high-fiber raw materials such as bamboo chips.

(3) Balance between output and environmental protection: The output of the pellet machine equipment can be adjusted according to the model. The density of the finished pellets reaches 0.9-1.4g/cm³ and the calorific value is 3500-5500 kcal. It can replace coal for power generation and heating, realizing the utilization of biomass energy.

3. Application scenarios of wet bamboo biomass pellet processing equipment

Industrial Heating Applications: Industries such as food processing (baking, sterilization), textile dyeing (steam heating), chemical processing (low-temperature reaction heating), and building materials (tile drying) require large amounts of low- to medium-temperature heat (80-300°C).  Biomass pellet boilers can provide stable steam or hot water at a cost that is only 60-70% of natural gas and 40-50% of electricity, making them widely used by small and medium-sized enterprises for cost reduction and emissions control.

Commercial Heating: Large public buildings such as hotels, schools, hospitals, and office buildings can use biomass pellet-fired central heating systems to replace traditional coal-fired boilers, meeting environmental standards (complying with national "ultra-low emission" standards).  Furthermore, the storage space required for pellet fuel is small, and refilling is infrequent.

2.图片


TONY Brand 15 Ton/Hour Wet Bamboo Pellet Manufacturing Plant can take wet bamboo as the main raw material. After pretreatment and processing, it is solidified into high - density bamboo pellet fuel. This fuel is an ideal substitute for coal and oil and plays a role in energy conservation and emission reduction. At present, it has been widely used in regions rich in bamboo resources.

1. Capacity: 15 Ton/Hour

2. Raw materials: Wet Bamboo

3. Moisture: Wet type, about 40%.

4. Application: All kinds of bamboo materials suitable for pellet production.

Suitable customers: Bamboo product processing companies, large-scale farms, agricultural/forestry parks, areas with dense bamboo resources, biomass energy companies/fuel traders, green environmental protection technology companies, and other places where bamboo raw materials have advantages

5. Finished Pellets Markets: Large power plants, domestic heating, industrial heating, combustion heat, heating systems, boiler rooms, school canteens, foundry heat sources.

3.图片


1. Project Name: Wet Bamboo Pellet Production Line

2. Raw Material: All kinds of wet bamboo

3. Moisture Content of Raw Material: 40%

4. Capacity: 15 tons per hour

5. Process: Crushing Process - Fine Crushing Process - Drying Process - Pelletizing Process - Cooling Process - Packing Process

6. Main Equipment: Comprehensive Chipper TPC1400-700-250KW, Effective Hammer Mill-TFD85*250-250kw, Rotary Drum Dryer-2.5*24m, TONY Pellet Machine TYJ760-Ⅲ-200kw, Galvanized Pellets Cooler, Ton Packing Machine and Belt Conveyors

4.图片



5.图片



3D图

3D图

3D图

5.1图片


1.Wet Bamboo To Bamboo Chips Process:

A.This process is mainly used to grind the bamboo whose diamater is under 35 cm into bamboo chips with size 25-55mm. The finish bamboo chips size can be adjustable by changing different sizes of screeners and adding flying knives inside the wood chipper.

B.TONY brand comprehensive chipper TPC1400-700-250Kw with 6 flying blades type*1 set

C.Capacity:20-30Ton/Hour.

Main Parts:

(1)TONY's Comprehensive Chipper.

(2)Feed And Discharge Belt Frequency Control To Prevent Card Material

(3)Hydraulic System Control Can Be Used For Thicker Materials

(4)Electronic Control System Allows The Equipment To Be Used Normally

Contact Tony For More Details With Quotation

5.2图片


2.Bamboo Chips Fine Crushing Process:

A.This process is mainly used to crush 25-55mm bamboo chips into 8-14mm bamboo dust.

B.Capacity:15 Ton/Hour.

C.TONY brand effective hammer mill TFD85*250-250kw*2 sets

Main Parts:

(1)TONY Effective Hammer Mill.

(2)Galvanized Dust Collector.

(3)Sawdust Transportation Fan Blower.

(4)Cyclone With Airlock.

(5)Electrical Cabinets.

5.3图片


3.Bamboo Dust Drying Process:

A.This process is mainly used to dry the bamboo dust  from 40% to 10-15%.

B.Capacity:15 Ton/Hour.

C.TONY use 2 sets of 2.5*24m  rotary drum dryer for this process, TONY hot blast stove is made of firebrick pan, shell with H steel plate as the frame.   There are 3 layers of fire blocking device inside, which can effectively prevent the fire from entering the tumble dryer.Customers can choose to use waste wood, biomass pellets, natural gas, etc. as fuel for the hot air furnace

TONY dryer use spiral tube material, and is not easy to deform.

Unlike other manufacturers with iron plate splicing welding, very easy to deformation.

Main Parts:

(1)TONY's Rotary Drum Dryer Main Body.  (Reducers With Motors and Pips.)

(2)TONY's  Hot Stove.

(3)Fan Blower+Cyclone With Airlock.

5.4图片


4.Pelletizing Process:

A.This process is mainly used to to product pellets into φ6-8mm.

B.Capacity:15Ton/Hour.

C.TONY brand vertical ring die pellet machine TYJ760-Ⅲ-200kw*5 sets

D.Double Screw Cycling Silo is added above the pellet machine, which has the advantages of saving space, saving labor, intelligently controlling the feeding speed, not easy to block the material, and improving production efficiency.

Main Parts:

(1)TONY's new Vertical Ring Die Pellet Machine.

(2)Cyclone And Bags Dust Collectors.

(3)Automatic Lubrication System.

(4)Electrical Cabinets.

You can chose TONY new type SS304 pellet machine

5.5图片


5.Cooling Process:

A.This process is mainly used to cool pellets from 80-90℃ to 20-30℃

B.Capacity:15 Ton/Hour.

C.TONY brand galvanized pellets cooler *1 set

Main Parts:

(1)TONY's new Galvanized Pellets Cooler With Vibrating Screen.

(2)Cyclone And Bags Dust Collectors.

(3)Fan Blower.

(4)Connect Pipes.

5.6图片


6.Packing Process:

A.This process is mainly used to pack pellets into 1 Ton/Bags.

B.Capacity:15 Ton/Hour.

C.TONY brand ton packing machine*1 set

Main Parts:

(1)TONY Ton Packing Machine

(2)Electronic Platform Scale Metering System

(3)Automatic Tare, Zero, and Drop Correction Functions

(4)Feeding System Features Fast, Medium, and Slow Feeding Speeds to Ensure Measuring Accuracy

6.图片


7.图片


Outstanding environmental benefits: When biomass pellets are burned, they primarily produce carbon dioxide and water, with extremely low emissions of pollutants such as sulfur dioxide, nitrogen oxides, and particulate matter.  Furthermore, because the raw materials absorb carbon dioxide during their growth, the overall lifecycle carbon emissions are nearly zero, making them highly environmentally friendly.

Excellent product characteristics: After processing and shaping, biomass pellets have significantly higher energy density, making them easier to store and transport.  Their regular shape and stable chemical composition result in a stable flame during combustion, with a calorific value generally between 3500 and 5000 kcal/kg and a combustion efficiency of up to 97%.  This makes them suitable for a wide range of heating and power generation applications.

8.图片


Storage and Transportation Advantages

High Density and Easy Storage: After compression molding, the volume is significantly reduced, making storage easier and preventing moisture damage.

Convenient Transportation: The regular shape facilitates mechanized loading, unloading, and transportation, reducing logistics costs.

Application Advantages

Wide Range of Applications: Suitable for industrial boilers, biomass power plants, home fireplaces, agricultural greenhouse heating, and other applications, serving as a viable alternative to traditional energy sources like coal and natural gas, offering high application flexibility. Easy to Use:  Can be fed automatically by equipment, simple to operate, and compatible with many existing combustion systems, requiring minimal equipment modifications.
