Project Brief Introduction:

1.Product:Dried Bagasse Pellet Line

2.Capacity: 3.5-4 T/Hour

3.TONY Brand 3.5-4 Ton /Hour Dried Bagasse Pellet Line Project Process

4.Main Machine:Hammer Mill,TONY Pellet Machine TYJ860-Ⅲ-250KW,Pellets Cooler,Packing Machine And Belt Conveyors

5.Total Power: About 410 kw

6.Need Area: About   ㎡  L:  M  W:  M  H:  M

Project Layout For Customer:

3D图

原材料图+颗粒机图片

1. The working principle of dried bagasse biomass pellet processing equipment

The dry sugarcane bagasse biomass pellet processing equipment converts loose sugarcane bagasse into high energy density, flammable and efficient clean fuel through physical compression + friction heat + natural bonding, reflecting the technical advantages of biomass energy resource utilization

2. Characteristics of dried bagasse biomass pellet processing equipment

(1) Economic benefits: low cost and high return

Low raw material cost: Bagasse is a waste product of the sugar industry. The acquisition cost is extremely low, or even free, which significantly reduces the input of raw materials.

Low equipment investment: The equipment of small and medium-sized production lines is simple to operate and can be used by ordinary people after training. The labor cost is low and the overall return on investment is high.

Potential for policy support: As a renewable energy project, it may enjoy local subsidies or tax incentives.

(2) Environmental protection and sustainability

Carbon neutrality: The carbon dioxide absorbed during the growth process of bagasse is balanced with the amount released during combustion. There is no additional carbon emission and no harmful gases such as sulfur dioxide are produced.

Renewable: Sugarcane can be planted every year, the raw material supply is stable, and it replaces fossil fuels to reduce resource consumption.

Turning waste into treasure: Solve the pollution problem of bagasse accumulation, increase farmers' income, and form a circular economy.

(3) Wide range of application scenarios

Bagasse pellets can be used for home heating, industrial boilers, biomass power plants, etc., covering multiple scenarios such as homes, enterprises, and power plants. The combustion efficiency is over 98%, meeting different heat energy needs.

(4) Efficient and stable equipment performance

High molding rate: The patented mold design enables a pellet molding rate of over 99.5%, reducing raw material waste.

Automation and durability: The equipment has a reasonable structure and the pressing wheel can be automatically adjusted to avoid machine jams, extend service life, and support continuous production.

3. Application scenarios of dried bagasse biomass pellet processing equipment

(1) Prioritize fuel applications: If there are sugar mills (raw material concentration), industrial enterprises, or heating needs in the area, it is recommended to prioritize fuel development, as raw material costs are low, market demand is stable, and the profit model is clearer.

(2) Supplementary feed applications: If the area is a concentrated cattle and sheep breeding area and there is an adequate supply of sugarcane bagasse from sugar mills, feed production can be considered as a supplement. However, it is necessary to focus on optimizing the conditioning formula to ensure that the feed is palatable and nutritious, and to avoid quality issues that affect market reputation.

2.图片

TONY Brand 3.5-4 Ton/Hour Dried Bagasse Pellet Manufacturing Plant can take dried bagasse as the main raw material. After pretreatment and processing, it is solidified into high - density Bagasse pellet fuel. This fuel is an ideal substitute for coal and oil and plays a role in energy conservation and emission reduction. At present, it has been widely used in regions rich in bagasse resources.

1. Capacity: 3.5-4 Ton/Hour

2. Raw materials: Dried bagasse

3. Moisture: dried type, about 10-15%.

4. Application: All kinds of bagasse materials suitable for pellet production.

Suitable customers: Sugarcane processing factories are the direct output of bagasse, such as sugar mills, sugarcane ethanol factories, sugarcane pulping factories, etc.; centralized storage and transit places, such as sugar mills, ethanol factories, agricultural product processing parks, where multiple sugarcane processing factories often gather to form a park. The storage and transit areas of bagasse are uniformly planned within the park, and the resource concentration is extremely high.and other places where bagasse raw materials have advantages

5. Finished Pellets Markets: Large power plants, domestic heating, industrial heating, combustion heat, heating systems, boiler rooms, school canteens, foundry heat sources.

3.图片


原材料--成品图

1. Project Name: Dried Bagasse Pellet Production Line

2. Raw Material: All kinds of dried bagasse

3. Moisture Content of Raw Material: 10-15%

4. Capacity: 3.5-4 tons per hour

5. Process: Fine Crushing Process -  Pelletizing Process - Cooling Process - Packing Process

6. Main Equipment:  Effective Hammer Mill-TFD75*100-110kw,  TONY Pellet Machine- TYJ860-Ⅲ-250kw, Galvanized Pellets Cooler, Semi-automatic Packing Machine and Belt Conveyors

4.图片

流程图1

流程图2

5.图片

原材料+颗粒图

颗粒+机器图

3D图

3D图

三维图

5.1图片

高效粉碎机

带锯末图

1.Bagasse Fine Crushing Process:

A.This process is mainly used to crush larger bagasse into 8-14mm bagasse.

B.Capacity:3-4 Ton/Hour.

C.TONY brand effective hammer mill TFD75*100-110kw*1set

Main Parts:

(1)TONY Effective Hammer Mill.

(2)Galvanized Dust Collector.

(3)Sawdust Transportation Fan Blower.

(4)Cyclone With Airlock.

(5)Electrical Cabinets.

5.2图片

颗粒机四件套带 原材料，颗粒图

2.Pelletizing Process:

A.This process is mainly used to to product pellets into φ6-8mm.

B.Capacity:3.5-4.5Ton/Hour.

C.TONY brand vertical ring die pellet machine TYJ860-III-250kw*1 set

Main Parts:

(1)TONY's new Vertical Ring Die Pellet Machine.

(2)Cyclone And Bags Dust Collectors.

(3)Automatic Lubrication System.

(4)Electrical Cabinets.

5.3图片

镀锌冷却仓加颗粒图

3.Cooling Process:

A.This process is mainly used to cool pellets from 80-90℃ to 20-30℃

B.Capacity:3.5-4 Ton/Hour.

C.TONY brand galvanized pellets cooler *1 set

Main Parts:

(1)TONY's new Galvanized Pellets Cooler With Vibrating Screen.

(2)Cyclone And Bags Dust Collectors.

(3) Fan Blower.

(4)Connect Pipes.

5.4图片

包装机

4.Packing Process:

A.This process is mainly used to pack pellets into 15-50KG/Bags.

B.Capacity:3.5-4 Ton/Hour.

C.TONY  brand semi-automatic packing machine*1 set

Main Parts:

(1)TONY Semi-Automatic Packing Machine.

(2)Sew Machine, Buyer Can Also Choose Hot Seal Machine For Chosen,To Confirm With Tony For The Price Difference.

(3)Bags Transportation Conveyors.

(4)Feeding Inlet Silo.

(5)Electrical Cabinets.

6.图片

客户生产线案例图

7.图片

图 干甘蔗渣+颗粒 颗粒机

Operational Advantages of Dry Bagasse Biomass Pellet Processing Projects

1. No Seasonal Restrictions on Raw Material Supply:

Dry bagasse can be stored for long periods (over a year in a dry, room-temperature environment), independent of the sugarcane crushing season. Bulk purchasing and staggered stockpiling can stabilize raw material supply, avoiding the "off-season raw material shortages" often associated with wet bagasse projects.

2. Reduced Environmental Compliance Pressure:

With no dust or exhaust emissions from the drying process, only a basic dust collector is required to meet environmental standards . The environmental impact assessment and approval process is simplified, shortening the project implementation cycle by 2-3 months compared to wet bagasse projects.

3. Equally Eligible for Policy Benefits:

This project falls under the "resource utilization of agricultural and forestry waste" category, qualifying for the same policies. Furthermore, lower energy consumption and carbon emissions further reduce operating costs.

8.图片

干甘蔗渣图 颗粒图

1. Processing adaptability

Sugar bagasse has a loose fiber structure. After crushing and extrusion molding, it is easy to form pellets with a density of 1.1-1.3g/cm³. During the molding process, lignin can naturally act as a binder, without the need to add chemical binders, ensuring the natural properties of the product.

2. Combustion performance: high calorific value and stable combustion

(1) Considerable energy density

The low calorific value of the molded sugar bagasse pellets is about 16-18MJ/kg, which is slightly lower than wood chip pellets (18-20MJ/kg), but higher than rice husk and straw pellets (13-15MJ/kg). It can meet the heat requirements of small and medium-sized boilers, household heating stoves and other equipment. Burning 1 ton of pellets is equivalent to the heat output of about 0.5 tons of standard coal.

(2) Strong combustion stability

The granular structure ensures uniform ventilation during combustion, making it less likely to cause "coking" (the ash content is only 2%-4%).The combustion efficiency can reach over 85%, which is more than double that of loose burning of sugarcane bagasse (efficiency of about 40%), and reduces the emission of unburned particulate matter in the flue gas.
