Project Brief Introduction:

1.Product:Wet Bagasse Pellet Line

2.Capacity: 10.5-12 T/Hour

3.TONY Brand 10.5-12 Ton /Hour Wet Bagasse Pellet Line Project Process

4.Main Machine:Hammer Mill, Rotary Drum Dryer,TONY Pellet Machine TYJ860-Ⅲ-250KW,Pellets Cooler,Packing Machine And Belt Conveyors

5.Total Power: About 1490 kw

6.Need Area: About   ㎡  L:  M  W:  M  H:  M

Project Layout For Customer:

3D图

原材料图+颗粒机图片

1. The working principle of wet bagasse biomass pellet processing equipment

The core principle of biomass pellet processing equipment (such as pellet mills) is to convert biomass feedstock into high-density pellet fuel through mechanical compression. The basic process involves three steps: feedstock pretreatment (crushing and drying), mechanical compression, and finished product processing (cooling and packaging). For example, in a ring die pellet mill, a motor connected to a reducer via a coupling drives the ring die. Feedstock enters the compression zone under gravity, where compression rollers squeeze the material into the ring die holes. After the pellets are formed in the die, a cutter cuts them into pellets of fixed lengths.

2. Characteristics of wet bagasse biomass pellet processing equipment

High adaptability to raw materials; capable of processing various types of biomass.

(1) Wide range of applicable raw materials:  Raw materials include wood (logs, wood chips, sawdust), agricultural crops (straw, rice husks, corn cobs, bagasse), herbaceous plants (reeds, grasses, bamboo), and nutshells (peanut shells, palm fiber). By adjusting the crushing and grinding parameters, the system can adapt to different raw materials with varying hardness and fiber content (e.g., hardwood requires stronger crushing capacity, while straw requires controlled particle size to prevent clumping).

(2) Specific requirements for raw material pretreatment: The moisture content of the raw material must be controlled between 10% and 15% (too high moisture content leads to sticking and clogging, while too low moisture content results in insufficient pellet strength), and the particle size is typically required to be between 4-14 mm. Therefore, the equipment system usually integrates drying and screening modules to ensure that the raw material meets the standards.

Modular design of core equipment for continuous production.

(1) Modular configuration: A typical production line consists of "crushing equipment (fine grinding) → drying equipment (moisture control) → pelletizing equipment (granulation) → cooling equipment (temperature reduction) → screening equipment (sorting) → packaging equipment." Each module can be flexibly added or removed based on production capacity requirements (e.g., smaller production lines can omit some auxiliary equipment).

(2) Continuous operation: Through the connection of conveyor belts, screw conveyors, and other equipment, automated continuous production from raw material input to finished product output is achieved.

3. Application scenarios of wet bagasse biomass pellet processing equipment

Core application areas: biomass energy production and application

The main product after wet bagasse processing is wet bagasse biomass pellets (or standard pellets after drying). Its core value lies in becoming a clean and renewable energy source that replaces traditional fossil fuels. Therefore, the energy field is the core application scenario of this equipment, including:

(1) Industrial heating/power generation field

Applicable scenarios: production heat (such as boiler heating, drying process) of small and medium-sized factories (such as food processing, textile, wood processing, chemical industry, etc.), power source of small generator sets.

(2) Civil heating/cooking field

Applicable scenarios: winter heating in areas rich in bagasse resources, home cooking or heating of small commercial places (such as homestays, bathing centers).

(3) Biomass power generation field

Applicable scenarios: fuel pretreatment link of small and medium-sized biomass power plants (installed capacity 10-30MW).

2.图

TONY Brand 10.5-12 Ton/Hour Wet Bagasse Pellet Manufacturing Plant can take wet bagasse as the main raw material. After pretreatment and processing, it is solidified into high - density Bagasse pellet fuel. This fuel is an ideal substitute for coal and oil and plays a role in energy conservation and emission reduction. At present, it has been widely used in regions rich in bagasse resources.

1. Capacity: 10.5-12 Ton/Hour

2. Raw materials: Wet bagasse

3. Moisture: Wet type, about 40%.

4. Application: All kinds of bagasse materials suitable for pellet production.

Suitable customers: Sugarcane processing factories are the direct output of bagasse, such as sugar mills, sugarcane ethanol factories, sugarcane pulping factories, etc.; centralized storage and transit places, such as sugar mills, ethanol factories, agricultural product processing parks, where multiple sugarcane processing factories often gather to form a park. The storage and transit areas of bagasse are uniformly planned within the park, and the resource concentration is extremely high.and other places where bagasse raw materials have advantages

5. Finished Pellets Markets: Large power plants, domestic heating, industrial heating, combustion heat, heating systems, boiler rooms, school canteens, foundry heat sources.

3.图

原材料--成品图

1. Project Name: Wet Bagasse Pellet Production Line

2. Raw Material: All kinds of wet bagasse

3. Moisture Content of Raw Material: 40%

4. Capacity: 10.5-12 tons per hour

5. Process: Fine Crushing Process - Drying Process - Pelletizing Process - Cooling Process - Packing Process

6. Main Equipment:  Effective Hammer Mill-TFD75*160-160kw, Rotary Drum Dryer-1.8*24m, TONY Pellet Machine- TYJ860-Ⅲ-250kw, Galvanized Pellets Cooler, Ton Packing Machine and Belt Conveyors

4.图

流程图1

流程图2

5.图

原材料+颗粒图

颗粒+机器图

3D图 图1-长宽

3D图  图2-高

三维图

5.1图

高效粉碎机

带锯末图

1.Bagasse Fine Crushing Process:

A.This process is mainly used to crush larger bagasse into 8-14mm bagasse.

B.Capacity:10-12 Ton/Hour.

C.TONY brand effective hammer mill TFD75*160-160kw*2sets

Main Parts:

(1)TONY Effective Hammer Mill.

(2)Galvanized Dust Collector.

(3)Sawdust Transportation Fan Blower.

(4)Cyclone With Airlock.

(5)Electrical Cabinets.

5.2图

烘干机

带锯末图

2.Wet Bagasse Drying Process:

A.This process is mainly used to dry the bagasse  from 40% to 10-15%.

B.Capacity:10-12 Ton/Hour.

C.TONY use 2 sets of 1.8*24m  rotary drum dryer for this process, TONY hot blast stove is made of firebrick pan, shell with H steel plate as the frame.   There are 3 layers of fire blocking device inside, which can effectively prevent the fire from entering the tumble dryer.Customers can choose to use waste wood, biomass pellets, natural gas, etc. as fuel for the hot air furnace

TONY dryer use spiral tube material, and is not easy to deform.

Unlike other manufacturers with iron plate splicing welding, very easy to deformation.

Main Parts:

(1)TONY's Rotary Drum Dryer Main Body.  (Reducers With Motors and Pips.)

(2)TONY's  Hot Stove.

(3)Fan Blower+Cyclone With Airlock.

5.3图

颗粒机四件套带 原材料，颗粒图

3.Pelletizing Process:

A.This process is mainly used to to product pellets into φ6-8mm.

B.Capacity:10.5-12Ton/Hour.

C.TONY brand vertical ring die pellet machine TYJ860-Ⅲ-250kw*3 sets

D.Double Screw Cycling Silo is added above the pellet machine, which has the advantages of saving space, saving labor, intelligently controlling the feeding speed, not easy to block the material, and improving production efficiency.

Main Parts:

(1)TONY's new Vertical Ring Die Pellet Machine.

(2)Cyclone And Bags Dust Collectors.

(3)Automatic Lubrication System.

(4)Electrical Cabinets.

5.4图

镀锌冷却仓加颗粒图

4.Cooling Process:

A.This process is mainly used to cool pellets from 80-90℃ to 20-30℃

B.Capacity:10.5-12 Ton/Hour.

C.TONY brand galvanized pellets cooler *1 set

Main Parts:

(1)TONY's new Galvanized Pellets Cooler With Vibrating Screen.

(2)Cyclone And Bags Dust Collectors.

(3)Fan Blower.

(4)Connect Pipes.

5.5图

吨包机图

5.Packing Process:

A.This process is mainly used to pack pellets into 1 Ton/Bags.

B.Capacity:10.5-12 Ton/Hour.

C.TONY brand ton packing machine*1 set

Main Parts:

(1)TONY Ton Packing Machine

(2)Electronic Platform Scale Metering System

(3)Automatic Tare, Zero, and Drop Correction Functions

(4)Feeding System Features Fast, Medium, and Slow Feeding Speeds to Ensure Measuring Accuracy

6.图

生产线案例图

7.图

图 湿甘蔗渣+颗粒 颗粒机

Project advantages: market competitiveness and environmental value

1. Excellent product characteristics and strong market competitiveness

Biomass pellets have many excellent characteristics. They have a high calorific value, generally 4200-4800 kcal/kg, close to medium-quality coal, and can provide sufficient heat; they have a low ash content, with very little ash residue after combustion, which reduces cleaning costs and reduces environmental pollution; they have low emissions, extremely low sulfur content (usually <0.05%), and low nitrogen content. Pollutants such as sulfur dioxide and nitrogen monoxide produced during the combustion process are much lower than those produced by burning coal, meeting strict environmental protection standards and are highly favored by customers with high environmental protection requirements. In addition, biomass pellets have a regular shape, mostly cylindrical, with a diameter of 6-12 mm and a length of 20-50 mm. The density can reach 0.8-1.2 g/cm3, high hardness, not easy to break, easy to store and transport, further enhancing the market competitiveness of the product.

2.Significant environmental benefits and high social value

The development of the biomass pellet industry aims to turn agricultural and forestry waste into treasure, realize resource recycling, and reduce waste pollution to the environment. At the same time, the carbon dioxide emitted during the combustion of biomass pellets is largely offset by the carbon dioxide absorbed by plant growth, achieving "carbon neutrality," helping to mitigate the greenhouse effect and improve air quality. This not only complies with national environmental protection policies but also helps entrepreneurs establish a positive corporate image, generating a good social reputation and potential business opportunities.

8.图

湿甘蔗渣图 颗粒图

The main advantages of bagasse pellets include environmental protection, economy and sustainability. ‌ bagasse pellets as a biomass fuel have many advantages, especially in terms of environmental protection and economic benefits ‌.

Firstly, bagasse pellets have significant advantages in terms of environmental protection. Bagasse is a renewable resource derived from agricultural waste, and the use of bagasse pellets can reduce dependence on fossil fuels and reduce greenhouse gas emissions. In addition, the ash produced by bagasse pellets during the combustion process can be used as a high-quality organic fertilizer to further promote the sustainable development of agriculture ‌.

Secondly, bagasse pellets also have economic advantages. The price of bagasse pellets is relatively low, the price of a ton of bagasse pellets is about 800 or 900 yuan, which is lower than the cost of traditional coal burning. This makes bagasse pellets competitive in the fuel market, especially today when energy costs are increasing, and bagasse pellets offer a more economical alternative ‌.

Finally, bagasse pellets offer sustainability benefits. Sugarcane is a crop with a short growth cycle, and bagasse as its by-product is rich in sources, which can ensure long-term stable supply. This will help reduce the dependence on limited resources and promote the development of a circular economy. ‌
