Project Brief Introduction:

1.Product:Wet Bagasse Pellet Line

2.Capacity:3-4 T/Hour

3.TONY Brand 3-4Ton /Hour Wet Bagasse Pellet Line Project Process

4.Main Machine:Hammer Mill, Rotary Drum Dryer,TONY Pellet Machine TYJ551-Ⅲ-110KW,Pellets Cooler,Packing Machine And Belt Conveyors

5.Total Power: About 440kw

6.Need Area: About   ㎡  L:  M  W:  M  H:  M

Project Layout For Customer:

3维图

原材料图+颗粒机图片

1. The working principle of wet bagasse biomass pellet processing equipment

The core principle of processing wet sugarcane bagasse into biomass pellets is to achieve dense molding by controlling material properties through pretreatment and synergizing mechanical and thermal effects, leveraging the raw material's inherent components. Essentially, this is a physical and chemical process that transforms loose, high-moisture bagasse into high-density, highly stable fuel pellets. This can be broken down into three key stages: pretreatment, core molding, and post-processing.

2. Characteristics of wet bagasse biomass pellet processing equipment

(1) Gear drive, strong extrusion force: The large gear drive system provides strong extrusion force to ensure the density and quality of the pellets.

(2) Low energy consumption, high output: The equipment design focuses on energy efficiency and can achieve higher output with lower energy consumption.

(3) Easy to operate: Biomass pellet processing equipment usually has a simple and easy-to-understand operation interface and process, which is convenient for workers to operate.

(4) Strong adaptability: It can adapt to different types and forms of sugarcane raw materials.

(5) Easy maintenance: The equipment structure design takes into account the convenience of daily maintenance, such as easy replacement of wear parts.

(6) High safety: Various safety protection measures are incorporated into the equipment design, such as devices to prevent the entry of hard objects such as metal, and emergency stop buttons, etc.

3. Application scenarios of wet bagasse biomass pellet processing equipment

(1) Industrial boiler fuel

Application targets: Industrial enterprises that require a stable heat source, such as textile mills, paper mills, food processing plants, and chemical plants (such enterprises traditionally rely on coal-fired boilers, which puts great pressure on environmental protection).

(2) Civilian clean heating/cooking

Application targets: Winter heating, home cooking, and decentralized energy needs in small places such as homestays and farmhouses.

(3) Biomass power generation/cogeneration

Application targets: Small and medium-sized biomass power plants (installed capacity 10-30MW), industrial park cogeneration projects (providing electricity and steam for the park).

(4) Agricultural and animal husbandry auxiliary

Application targets: Organic fertilizer production enterprises, flower and seedling planting bases.

2图

TONY Brand 3-4 Ton/Hour Wet Bagasse Pellet Manufacturing Plant can take wet bagasse as the main raw material. After pretreatment and processing, it is solidified into high - density Bagasse pellet fuel. This fuel is an ideal substitute for coal and oil and plays a role in energy conservation and emission reduction. At present, it has been widely used in regions rich in bagasse resources.

1. Capacity: 3-4 Ton/Hour

2. Raw materials: Wet bagasse

3. Moisture: Wet type, about 40%.

4. Application: All kinds of bagasse materials suitable for pellet production.

Suitable customers: Sugarcane processing factories are the direct output of bagasse, such as sugar mills, sugarcane ethanol factories, sugarcane pulping factories, etc.; centralized storage and transit places, such as sugar mills, ethanol factories, agricultural product processing parks, where multiple sugarcane processing factories often gather to form a park. The storage and transit areas of bagasse are uniformly planned within the park, and the resource concentration is extremely high.and other places where bagasse raw materials have advantages

5. Finished Pellets Markets: Large power plants, domestic heating, industrial heating, combustion heat, heating systems, boiler rooms, school canteens, foundry heat sources.

3图


原材料--成品图

1. Project Name: Wet Bagasse Pellet Production Line

2. Raw Material: All kinds of wet bagasse

3. Moisture Content of Raw Material: 40%

4. Capacity: 3-4 tons per hour

5. Process: Fine Crushing Process - Drying Process - Pelletizing Process - Cooling Process - Packing Process

6. Main Equipment:  Effective Hammer Mill-TFD75*100-110kw, Rotary Drum Dryer-1.8*18m, TONY Pellet Machine- TYJ551-Ⅲ-110kw, Galvanized Pellets Cooler, Semi-automatic Packing Machine and Belt Conveyors

4图

流程图1

流程图.

5.图片

原材料+颗粒图

颗粒+机器图

三维图

三维图

3维图

5.1图

高效粉碎机

带锯末图

1.Bagasse Fine Crushing Process:

A.This process is mainly used to crush larger bagasse into 8-14mm bagasse.

B.Capacity:3-4 Ton/Hour.

C.TONY brand effective hammer mill TFD75*100-110kw*1set

Main Parts:

(1)TONY Effective Hammer Mill.

(2)Galvanized Dust Collector.

(3)Sawdust Transportation Fan Blower.

(4)Cyclone With Airlock.

(5)Electrical Cabinets.

5.2图

烘干机

带锯末图

2.Wet Bagasse Drying Process:

A.This process is mainly used to dry the bagasse  from 40% to 10-15%.

B.Capacity:3-4 Ton/Hour.

C.TONY use 1 set of 1.8*18m  rotary drum dryer for this process, TONY hot blast stove is made of firebrick pan, shell with H steel plate as the frame.   There are 3 layers of fire blocking device inside, which can effectively prevent the fire from entering the tumble dryer.Customers can choose to use waste wood, biomass pellets, natural gas, etc. as fuel for the hot air furnace

TONY dryer use spiral tube material, and is not easy to deform.

Unlike other manufacturers with iron plate splicing welding, very easy to deformation.

Main Parts:

(1)TONY's Rotary Drum Dryer Main Body.  (Reducers With Motors and Pips.)

(2)TONY's  Hot Stove.

(3)Fan Blower+Cyclone With Airlock.

5.3图

颗粒机四件套带 原材料，颗粒图

3.Pelletizing Process:

A.This process is mainly used to to product pellets into φ6-8mm.

B.Capacity:3-4Ton/Hour.

C.TONY brand vertical ring die pellet machine TYJ551-III-110kw*2 sets

D.Double Screw Cycling Silo is added above the pellet machine, which has the advantages of saving space, saving labor, intelligently controlling the feeding speed, not easy to block the material, and improving production efficiency.

Main Parts:

(1)TONY's new Vertical Ring Die Pellet Machine.

(2)Cyclone And Bags Dust Collectors.

(3)Automatic Lubrication System.

(4)Electrical Cabinets.

5.4图

镀锌冷却仓加颗粒图

4.Cooling Process:

A.This process is mainly used to cool pellets from 80-90℃ to 20-30℃

B.Capacity:3-4 Ton/Hour.

C.TONY brand galvanized pellets cooler *1 set

Main Parts:

(1)TONY's new Galvanized Pellets Cooler With Vibrating Screen.

(2)Cyclone And Bags Dust Collectors.

(3) Fan Blower.

(4)Connect Pipes.

5.5图

包装机

5.Packing Process:

A.This process is mainly used to pack pellets into 15-50KG/Bags.

B.Capacity:3-4 Ton/Hour.

C.TONY  brand semi-automatic packing machine*1 set

Main Parts:

(1)TONY Semi-Automatic Packing Machine.

(2)Sew Machine, Buyer Can Also Choose Hot Seal Machine For Chosen,To Confirm With Tony For The Price Difference.

(3)Bags Transportation Conveyors.

(4)Feeding Inlet Silo.

(5)Electrical Cabinets.

6图

客户生产线案例图

7图

图 湿甘蔗渣+颗粒 颗粒机

The core value of the wet sugarcane bagasse biomass pellet project:

1.Volume reduction: After wet sugarcane bagasse waste is processed into pellets, its volume is reduced to 1/4-1/5 of its original size. The waste that originally needed to be stored in a rented space can now be converted into compact pellets for storage, saving storage costs;

2.Resource-based income generation: If the pellets are used for self-use (such as factory boiler heating and drying bamboo products), they can replace purchased fuel and reduce energy costs; if they are sold to biomass power plants and fuel dealers, they can form an additional profit point of "waste-product-income"

3.Drive farmers' income growth: Farmers can sell the previously discarded sugarcane to the processing center to increase additional income;

4.Improve the rural environment: Avoid air pollution caused by farmers' arbitrary burning of sugarcane waste, and avoid the safety hazards of mosquito breeding and fire caused by the stacking of waste;

5.Help rural revitalization: The centralized processing center can absorb local labor (such as raw material procurement, equipment operation, and pellet sales), forming a rural industrial chain of "sugarcane bagasse resources-processing-sales".

8图

湿甘蔗渣图 颗粒图

1. Processing adaptability

Sugar bagasse has a loose fiber structure. After crushing, drying (moisture content reduced to 12%-15%), and extrusion molding, it is easy to form pellets with a density of 1.1-1.3g/cm³. During the molding process, lignin can naturally act as a binder, without the need to add chemical binders, ensuring the natural properties of the product.

2. Combustion performance: high calorific value and stable combustion

(1) Considerable energy density

The low calorific value of the molded sugar bagasse pellets is about 16-18MJ/kg, which is slightly lower than wood chip pellets (18-20MJ/kg), but higher than rice husk and straw pellets (13-15MJ/kg). It can meet the heat requirements of small and medium-sized boilers, household heating stoves and other equipment. Burning 1 ton of pellets is equivalent to the heat output of about 0.5 tons of standard coal.

(2) Strong combustion stability The granular structure ensures uniform ventilation during combustion, making it less likely to cause "coking" (the ash content is only 2%-4%).

The combustion efficiency can reach over 85%, which is more than double that of loose burning of sugarcane bagasse (efficiency of about 40%), and reduces the emission of unburned particulate matter in the flue gas.
