Project Brief Introduction:

1.Product:Wet Bagasse Pellet Line

2.Capacity: 2-2.5 T/Hour

3.TONY Brand 2-2.5 Ton /Hour Wet Bagasse Pellet Line Project Process

4.Main Machine:Hammer Mill, Rotary Drum Dryer,TONY Pellet Machine TYJ551-III-132KW,Pellets Cooler,Packing Machine And Belt Conveyors

5.Total Power: About 270 kw

6.Need Area: About   ㎡  L:  M  W:  M  H:  M

Project Layout For Customer:

3维图

原材料图+颗粒机图片

1. The working principle of wet bagasse biomass pellet processing equipment

The principle of wet bagasse pellet processing equipment is to squeeze wet bagasse into pellets by physical means. During the pelletizing process, the biomass bagasse raw material falls vertically from the feed port, and the rotation of the pressing roller makes the material continuously and evenly distributed on the surface of the inner cavity of the mold. Under the rolling of the pressing roller, the powdered material passes through the holes of the mold. In this process, the material is subjected to high pressure and high temperature, which causes physical changes or appropriate chemical changes, prompting the powdered material to form a continuously elongated cylindrical solid body. The pellets are then cut by a cutting knife and discharged from the discharge port, completing the pellet pressing process.

2. Characteristics of wet bagasse biomass pellet processing equipment

(1)Efficient Drying: Wet bagasse has a high moisture content and typically requires drying to reduce it to within 10-15%.Efficient drying equipment ensures that the bagasse reaches the appropriate moisture content quickly, improving the effectiveness of the subsequent pelletizing process.

(2) Durability: In a sugarcane pellet machine, dies and rollers are consumable components, so processing equipment must be durable and have a long service life. Users should pay attention to maintenance. Our company uses highly wear-resistant dies and rollers, which offer significantly longer service life and higher yields than standard equipment.

(3) High Level of Automation: Modern wet bagasse pellet processing equipment is typically equipped with automated control systems, enabling continuous production, reducing manual intervention, and improving production efficiency and product quality consistency.

(4)Environmental Protection and Energy Saving: With growing environmental awareness, processing equipment should be energy-efficient and emission-reducing to minimize environmental impact. For example, using drying equipment with high thermal efficiency can reduce energy consumption.

(5) Adaptability: Processing equipment should be flexible and adaptable to varying raw material characteristics and production scales.

3. Application scenarios of wet bagasse biomass pellet processing equipment

(1)Hot Water and Industrial Boilers: This pellet fuel is suitable for hot water boilers and industrial boilers, providing a stable heat source.

(2)Biomass Power Plants: Wet sugarcane bagasse pellets are an important fuel source for biomass power plants, contributing to sustainable energy utilization.

(3) Agriculture and Forestry: In agricultural production, the ash from combustion can be used directly as potash fertilizer to promote crop growth. Furthermore, the production of wet sugarcane bagasse pellets can help dispose of agricultural waste and reduce environmental pollution.

(4)Environmental Protection: Because wet sugarcane bagasse pellets are renewable and do not release other harmful gases during combustion, their use is environmentally friendly and helps reduce greenhouse gas emissions.

2.图片

TONY Brand 2-2.5 Ton/Hour Wet Bagasse Pellet Manufacturing Plant can take wet bagasse as the main raw material. After pretreatment and processing, it is solidified into high - density Bagasse pellet fuel. This fuel is an ideal substitute for coal and oil and plays a role in energy conservation and emission reduction. At present, it has been widely used in regions rich in bagasse resources.

1. Capacity: 2-2.5 Ton/Hour

2. Raw materials: Wet bagasse

3. Moisture: Wet type, about 40%.

4. Application: All kinds of bagasse materials suitable for pellet production.

Suitable customers: Sugarcane processing factories are the direct output of bagasse, such as sugar mills, sugarcane ethanol factories, sugarcane pulping factories, etc.; centralized storage and transit places, such as sugar mills, ethanol factories, agricultural product processing parks, where multiple sugarcane processing factories often gather to form a park. The storage and transit areas of bagasse are uniformly planned within the park, and the resource concentration is extremely high.and other places where bagasse raw materials have advantages

5. Finished Pellets Markets: Large power plants, domestic heating, industrial heating, combustion heat, heating systems, boiler rooms, school canteens, foundry heat sources.

3.图片


1. Project Name: Wet Bagasse Pellet Production Line

2. Raw Material: All kinds of wet bagasse

3. Moisture Content of Raw Material: 40%

4. Capacity: 2-2.5 tons per hour

5. Process: Fine Crushing Process - Drying Process - Pelletizing Process - Cooling Process - Packing Process

6. Main Equipment: Effective Hammer Mill-TFD65*75-55kw, Rotary Drum Dryer-1.8*12m, TONY Pellet Machine- TYJ551-Ⅲ-132kw, Galvanized Pellets Cooler, Semi-automatic Packing Machine and Belt Conveyors

4.图片



5.图片



三维图

三维图

3维图

5.1图片


1.Bagasse Fine Crushing Process:

A.This process is mainly used to crush larger bagasse into 8-14mm bagasse.

B.Capacity:2-2.5 Ton/Hour.

C.TONY brand effective hammer mill TFD65*75-55kw*1set

Main Parts:

(1)TONY Effective Hammer Milll.

(2)Galvanized Dust Collector.

(3)Sawdust Transportation Fan Blower.

(4)Cyclone With Airlock.

(5)Electrical Cabinets.

5.2图片


2.Wet Bagasse Drying Process:

A.This process is mainly used to dry the bagasse  from 40% to 10-15%.

B.Capacity:2-2.5 Ton/Hour.

C.TONY use 1 set of 1.8*12m  rotary drum dryer for this process, TONY hot blast stove is made of firebrick pan, shell with H steel plate as the frame.   There are 3 layers of fire blocking device inside, which can effectively prevent the fire from entering the tumble dryer.Customers can choose to use waste wood, biomass pellets, natural gas, etc. as fuel for the hot air furnace

TONY dryer use spiral tube material, and is not easy to deform.

Unlike other manufacturers with iron plate splicing welding, very easy to deformation.

Main Parts:

(1)TONY's Rotary Drum Dryer Main Body.  (Reducers With Motors and Pips.)

(2)TONY's  Hot Stove.

(3)Fan Blower+Cyclone With Airlock.

5.3图片


3.Pelletizing Process:

A.This process is mainly used to to product pellets into φ6-8mm.

B.Capacity:2-2.5Ton/Hour.

C.TONY brand vertical ring die pellet machine TYJ551-III-132kw*1 set

Main Parts:

(1)TONY's new Vertical Ring Die Pellet Machine.

(2)Cyclone And Bags Dust Collectors.

(3) Automatic Lubrication System.

(4)Electrical Cabinets.

5.4图片


4.Cooling Process:

A.This process is mainly used to cool pellets from 80-90℃ to 20-30℃

B.Capacity:2-2.5 Ton/Hour.

C.TONY brand galvanized pellets cooler *1 set

Main Parts:

(1)TONY's new Galvanized Pellets Cooler With Vibrating Screen.

(2)Cyclone And Bags Dust Collectors.

(3)Fan Blower.

(4)Connect Pipes.

5.5图片


5.Packing Process:

A.This process is mainly used to pack pellets into 15-50KG/Bags.

B.Capacity:2-2.5 Ton/Hour.

C.TONY  brand semi-automatic packing machine*1 set

Main Parts:

(1)TONY Semi-Automatic Packing Machine.

(2)Sew Machine, Buyer Can Also Choose Hot Seal Machine For Chosen,To Confirm With Tony For The Price Difference.

(3)Bags Transportation Conveyors.

(4)Feeding Inlet Silo.

(5)Electrical Cabinets.

6.图片


7.图片

图 湿甘蔗渣+颗粒 颗粒机

Leveraging the technological advantages of our wet sugarcane bagasse pelletizing equipment, the project can be gradually expanded and upgraded: initially focusing on biomass pellet fuel production to accumulate technology and capital; in the mid-term, developing pellet-derived products such as organic seedling growing media and biochar fertilizers; and in the long term, establishing a complete value chain from sugarcane cultivation to sugar processing, bagasse pellet production, and carbon trading, thus creating a regional model project for agricultural waste resource utilization and achieving greater economic and ecological benefits.

8.图片

湿甘蔗渣图 颗粒图

1. Low emissions of combustion pollutants: The raw material, sugarcane bagasse, has a sulfur content of ≤0.1% and a nitrogen content of ≤0.5%. During combustion, the sulfur dioxide emissions are <50mg/m³ and the nitrogen oxide emissions are <150mg/m³, which are only 1/3 and 1/2 of the national coal-fired emission standards, respectively.  Furthermore, there are no emissions of toxic substances such as heavy metals. It can directly replace coal used in industrial boilers and heating systems, helping enterprises meet environmental standards and avoid environmental penalties.

2. Carbon reduction throughout the entire lifecycle: The carbon dioxide absorbed by sugarcane during its growth can offset the carbon dioxide released during the combustion of the pellets, forming a "carbon cycle."  It is both a clean energy carrier and an important tool for enterprises to achieve their "dual carbon" goals.

3. Resource utilization of agricultural waste to reduce pollution: my country produces a large amount of sugarcane bagasse annually. If left unmanaged or burned directly, it can produce foul-smelling gases and pollute soil and water. Converting sugarcane bagasse into high-value energy through pelletization achieves "waste-to-resource" utilization, bringing both economic and environmental benefits.

9.图片

绿色地球+原材料+颗粒图
