TONY Straw pellet machine is based on crop straw as the main raw material, such as corn straw, wheat straw, soybean straw, cotton straw, etc., after crushing and other pretreatment, the straw pelletizing machine is pressed into cylindrical particles. Straw particles have the characteristics of high density, high molding rate and high calorific value. According to the quality of raw materials, extruded particles can be used as biomass fuel or livestock feed.

As we all know, straw is a very important and extensive biomass resource. Without adding any additives, it can be made into straw particles with high density, high molding rate and high calorific value, which can realize the resource utilization of corn straw and realize the transformation of waste into treasure, which is of great significance to the sustainable development of agriculture, the increase of farmers' income and the creation of a green ecological environment.

Straw pellets can not only meet the huge demand for clean energy of ordinary families, but also be applied to industrial energy, and large-scale production can also apply for state subsidies, which is the direction of industrial policy advocacy in many countries.

TONY's straw pellet machine mainly has 4 parts:

1.TONY new 304 stainless steel vertical ring die pellet machine

2. The rollers automatic lubrication system contains galvanized grease storage barrel.

3. New cyclone and dust bag collect system, including fan and pipe and dust collection bucket.

4. Electrical control system for all the above equipment.

A. Capacity:2-2.5Ton/Hour

B.Main Machine Power:132KW

C.Type: Vertical Ring Die Type With 2 Layers.

TONY Straw Pellet Machine has a variety of models, according to the customer production of different models, pellet machine factory price from USD20000-USD70000.

You get what you pay for. The price always depends on the value. Because the pellet machine market is currently more chaotic, customers must be careful to buy!

To make a purchase decision after a comprehensive inspection of a number of comprehensive indicators such as product quality, manufacturer scale strength, pre-sales and after-sales service ability, research and development design ability, rather than just looking at the price!

Please note:

If your purchase cost is very low, the later use cost will be very high!

Because the purchase of very low cost equipment is likely to cause you to face endless maintenance later, continuous downtime and maintenance will delay your production and make you pay more money.

Main Pellet Machine
1.SS304type
2.Capacity:1-5T/hour (It depends on clients raw materials)
3.Power:90kw-280kw(Stripping Material Motors)
4.Motors can be changed to frequency motors according to clinets' demand
5.Use HUIXIN Brand TONY Custom-made bigger and heavier gearbox.

Automatic Lubrication System for Rollers Bearings
1.Automatic Grease lubrication system for rollers bearings.
2.Automatic Grease lubrication system for main shaft bearings.
3.It can keep the pellet machine in maintenance for 20 hours.
4.Automatic fixed time lubrication.Customer can set time by himself.
5.Increase the oil circuit failure alarm device, once blocked, alarm immediately.

Cyclone and dust Collecter

1.It is mainly used to collect dust that come out of pellet machine during producing the pellets.

2. There are 3 dust removal interfaces, respectively connected to the pellet machine 2 steam outlet, pellet machine bearing room dust discharge hole to remove the dust.

3.New cyclone and dust bag collect system, including fan and pipe and dust collection bucket.

Motors

1.TONY Motors uses Qingao SHUOBO Brand.

2.Pure copper national standard motor.

3.The motors can also be changed into a variable frequency motor according to customer needs. Please consult TONY for the price difference of variable frequency motor.

4.You can also chose your motor brand by consulting TONY price difference.

Galvanized Belt Conveyor
1. It is used to transport the  sawdust to the pellet machine, optional according to customer needs.
2. If  customer digs a pit, you will need belt conveyor with   50cm width and 10 meters length .
If customer does not dig a pit, you will need belt conveyor with   50cm width and 8 meters length .
3. The belt conveyor needs to be equipped with a frequency converter to achieve one-button simultaneous operation with the pellet machine, and control the conveying speed of the belt conveyor by sensing the current of the pellet machine.

Screw Conveyor
1.  It is used to transport the  sawdust to the pellet machine, optional according to customer needs.
2. If  customer digs a pit, you will need  screw conveyor with φ219 and 6m length.
If customer does not dig a pit, you will need  screw conveyor with φ219 and 6m length.
3. The screw conveyor needs to be equipped with a frequency converter to achieve one-button simultaneous operation with the pellet machine, and the conveying speed of the screw conveyor is controlled by sensing the current of the pellet machine.

Electrical Cabinets

1.We use well-known Chinese brand electrical components, and we can also choose Schneider and Siemens electrical appliances according to customer requirements. Please consult Tony for the price difference.

2.TONY pellet machine has a one-button start function to prevent the machine from being damaged due to incorrect operation by customers who do not know the start-up sequence.

3.The control panel has 3 sound and light buzzers.

One is the lubrication fault alarm indicator. When the automatic lubrication system of the roller and the automatic lubrication pump of the gear box are not started or fail during operation or are overloaded during operation, the alarm indicator will light up.

One is when the automatic lubrication system of the roller is overpressured, the alarm indicator will light up.

One is when the main machine of the pellet machine is overheated, the alarm indicator will light up.

4.If the customer chooses a variable frequency motor, all components in the electric control cabinet need to adopt variable frequency control. Please contact Tony to obtain the price difference of the variable frequency control cabinet.

1.Materials:Bearing Steel GCr13,hardness above HRC62.

2.Double-lay die, dual use.Service Time: 1000-1500 hours

3.Hole diameter:4mm, 6mm, 8mm, 10mm, 12mm

1.Materials: Bearing Steel GCr13

2.Service:500-600 hours

3.TONY 110KW pellet machine has 2 rollers as a group.

1.Materials: Bearing Steel GCr13

2.Service:500-600 hours

3.According to actural factors, such as capacity and raw material, two or three or four rollers are used.

1.China HRB Bearings.

2.Genuine Haerbin bearings Longer service life.

3.Larger bearings inside.

1. TONY Pellet Machine can press a variety of biomass raw materials, different raw materials only need to replace the ring die.

2. Each raw material corresponds to a ring die with a compression ratio. If you have a variety of raw materials later, it is recommended to buy ring dies with different compression ratios from TONY.

3. The compression ratio of ring die is set by TONY according to his experience for many years. If the customer changes the raw materials, the ring die must be replaced.

4. The ring die of TONY brand is vertical and double-layer ring die. Each time the particles are pressed, only the lower layer of ring die can press the particles. When the life of the lower layer of ring die ends, the mold can be turned to use the other ring die.

5. The life of TONY ring die is generally 1000-1500 hours, and the service life of ring die is different according to the different raw materials of customers.

6. The material of TONY ring die is alloy steel-bearing steel. After quenching heat treatment, the hardness is higher, the wear resistance is greater, and the service life is longer.
