TONY Three-Layer Rotary Drum Dryer is on the basis of a single cylinder dryer, the three different diameter of the drum assembly together, generally adopt tug drive, driven by 2-4 motors, by a frequency converter to control synchronization. The horizontal installation of the cylinder has no inclination, the installation is relatively simple, and the floor area is small. Because the middle cylinder and outer cylinder of the three-cylinder dryer are completely sealed, while greatly improving the thermal efficiency, it also causes maintenance difficulties; In the design and production, we should fully consider the material of the equipment, the robustness of the lifting board and other factors, and design a reasonable and fine three-cylinder dryer to greatly improve the life.

TONY Three-Layer Rotary Drum Dryer is suitable for granular materials, but it is not suitable for viscous materials, slender materials, and large materials.Raw materials need a certain percentage of moisture to be made into high-quality pellets. The drum dryer can help you dry the moisture content of the raw materials from 60% to about 10%.

In the drying operation of wood chips, the whole drying process is the full heat of the material and high temperature air flow. The design concept of the three-cylinder dryer is: the initial heating of the inner cylinder, that is, the preheating stage, high temperature drying; In the middle cylinder is the constant temperature heat exchange process; The outside is low temperature.

TONY Three-Layer Rotary Drum Dryer An improved energy-saving product based on the single cylinder rotary drum dryer. Improve the internal structure of the original single Drum Dryer, increase the pre-drying of wet materials before the machine and extend the drying time of wet materials in the machine, coupled with sealing, heat preservation and reasonable supporting measures, so that the production capacity of the dryer is increased by 50-80% compared with the original single drum dryer. The unit volume evaporation intensity can reach 120-180kg/m3, and the standard coal consumption is only 6-8kg/t. Its advanced technology, reasonable operating parameters, simple and feasible operation, widely used in various industries of slag, clay, coal

TONY Three-Layer Rotary Drum Dryer is to change the single cylinder body of the single cylinder dryer into three cylinders stacked together to shorten the outline size of the drying body. When the machine is working, the material and hot gas flow into the inner to outer cylinder in turn, after the Z-shaped reciprocating flow of the body, the heat energy is fully used to dry the material before unloading.

The cylinder part of TONY Three-Layer Rotary Drum Dryer is composed of three inner, middle and outer cylinders placed horizontally, which makes the cross section of the cylinder be fully utilized. The total length of the cylinder shape is about 30-35% of the equivalent monocular length. Thus greatly reduce the floor area and plant building area

The supporting device of TONY Three-Layer Rotary Drum Dryer is the supporting device of the wheel belt and the supporting wheel on the outer cylinder, and the supporting wheel is directly driven by the motor. The cylinder is rotated by friction between the support wheel and the belt. The overall structure of the machine is compact, reasonable and simple, in order to facilitate the maintenance and replacement of wear parts, the axial split type is designed in the middle, and the bolt is fixed and connected.

1.Feeding System

It is used to bring the material with relatively high humidity into the dryer for drying. Feeding system mainly includes hopper, conveyor and so on.

2.Three Cylinders

The three-cylinder dryer is mainly composed of three rotating cylinders installed in parallel, and there are loose holes on the wall of the cylinder for air discharge and air intake. The three cylinders are independent of each other, and each completes the drying work, and the hot air passes through it for heat transfer. The method of "common heat, common smoke, common gas, and single force" is adopted between the three cylinders to make the drying operation more scientific and reasonable.

3.Hot Air System

It is a key component of the three-cylinder dryer, which is responsible for transporting hot air to the rotating cylinder for drying. The hot air system consists of blast fan, hot air boiler, hot air pipeline, etc.

4.Discharge System.

It is used to discharge the materials after drying treatment, as well as the exhaust gas and dust generated in the drying process. The discharge system includes discharge port, exhaust gas discharge pipe, dust collector, etc.

5.Control System.

It is mainly used to control the start and stop of the dryer, heating, gas supply and other operations. The control system usually adopts PLC program control, and realizes man-machine interaction through touch screen interface, which improves the automation level of machine equipment.

The material enters the inner Layer of the rotary drum by the feeding device to realize the downstream dry supply under the sheet plate of the upper inner layer, and the scattered product realizes heat exchange by spiraling. The material moves to the inner product and slides into the middle layer for countercurrent dry supply. The material is repeatedly lifted into the middle layer in a two-step way. The material in the middle layer not only fully absorbs the heat emitted by the inner cylinder, but also absorbs the heat before the middle layer is rolled, and at the same time extends the drying time, the material reaches the most dry state here. Material line to middle layer another. The end falls into the outer layer, and the material travels in a rectangular multi-loop mode in the outer roller, and the material that achieves the drying effect travels rapidly under the action of hot air and is discharged from the roller, while the wet material that does not achieve the drying effect cannot travel rapidly due to its own weight, and the material is fully dried in the rectangular sheet to complete the drying purpose. (combination of monobar and air flow), diameter 1.8-3.5 meters, generally 2.2 meters. Compact structure, space saving

TONY Three-Layer Rotary Drum Dryer Compact structure, simple structure, reasonable layout, improve the heat exchange rate of materials and heat energy, so that the drying effect of materials is good; The basic investment is less, which is only half of the same output of the single cylinder dryer, reducing the one-time investment; TONY Three-Layer Rotary Drum Drye reliable operation, low energy consumption, high thermal efficiency; At the same time, it is easy to realize automatic control, reduce operators and save labor resources.

TONY Three-Layer Rotary Drum Dryer is a three-return tumble dryer that is replaced by a traditional single-return tumble dryer that is stacked together to shorten the overall size of the dryer body. When the machine is working, the material and hot gas flow enter from inside to outside in turn, and after the Z-shaped reciprocating baffle of the body, the heat energy is fully used to dry the material before unloading.

TONY Three-Layer Rotary Drum Dryer Adopts Mosaic structure. The inner cylinder, the middle cylinder and the outer cylinder form a self-insulating structure. At the same time, the roller is outfitted with insulation materials and stainless steel plates to further reduce heat loss and improve thermal efficiency. Special thermal design concept, eliminate wind tunnel heat loss. Increase heat exchange area and evaporation intensity per unit volume. The heat energy utilization rate is significantly enhanced, and the thermal efficiency is effectively increased by 40% to save more than double the energy consumption. The reduction of the footprint of the three-cylinder dryer. Reduced customer base investment. Can adapt to coal, oil, gas and other fuels, customers can choose freely according to their own conditions.

1.The material of the three-return drum drying equipment can be made of high manganese steel, alloy steel, etc., which is 3-4 times wear-resistant than ordinary steel plates.

2. The initial moisture of the material is 60%, and the final moisture is about 10%, which is the main product of the biomass pellet production line.

3. Three return tumble dryer thermal efficiency up to 80 ~ 90% (traditional single cylinder thermal efficiency is only 35-60%), greatly improve the thermal efficiency;

4.Total power reduction, power saving 40%; It can save costs for enterprises.

5.Can dry 20-40mm below the block, particle, powder materials;

6.The three-return tumble dryer than the single-cylinder dryer to reduce the floor area of about 40%, for enterprises to save civil construction investment.

7.Greatly reduce the air leakage phenomenon, solve the sealing difficulties, can be installed within a few hours.

8.TONY Three-Layer Rotary Drum Dryer outlet temperature is low, conducive to the use of dust removal equipment for a long time, can be directly supporting the air box pulse bag dust collector.

9. Civil investment is reduced by about 50%, and electricity consumption is reduced by 60%.

10.TONY Three-Layer Rotary Drum Dryer does not need large or small gear rotation, using a rotary drum dryer.

The three-way dryer is mainly used for drying granular materials within a certain humidity and particle size range and other small granular materials that are not afraid of high temperature and dust.

Applicable materials also include sand, sludge, sand and stone, coal mud, fly ash, slag, chicken manure, wood chips, sawdust, grain and other materials.

High Drying Efficiency: the three-way dryer has the functions of guiding, lifting and so on, so that the material is heated evenly in the cylinder, according to the requirements of the material in the industry, the material with different humidity comes out of the dryer after the water content is qualified

Low Drying Cost: The three-return dryer adopts the sleeve design, the heat energy is transferred back and forth in the cylinder, reducing the loss of heat, compared with the traditional single-cylinder dryer, the heat preservation efficiency is doubled, and the coal consumption is only one-third of the single-cylinder dryer. Not only that, the volume of the three-return dryer is also reduced by 40% compared with the single-cylinder dryer, which reduces the cost of civil construction by about 60%

Environmental Protection And Energy Saving: the external surface area of the three-return dryer is reduced by more than 30% than that of the single-cylinder rotary dryer, and the outer cylinder has a thermal insulation effect on the inner cylinder, the outer cylinder surface temperature is low, and the heat loss is less, which greatly improves the working environment and working conditions while saving energy

Main Three-Layer Rotary Drum Dryer 1.Three return tumble dryer 2.Three rollers of different diameters are assembled 3.The material is made of high quality plate, which is 3-4 times wear-resistant than ordinary steel plate. 4.To dry the wet raw materials Frequency dryer body. 5.The middle cylinder and the outer cylinder are completely sealed
	Hot Blast Stove 1. Made of refractory material, refractory brick pan. 2. It can use coal or any biomass raw material as fuel. Wider applicability 3. Using pipeline air supply, heating speed is fast and thermal efficiency is higher 4. Good fire insulation effect. Save energy consumption and reduce enterprise costs 5. Easy to start and stop, safe 6. Provide design drawings, the buyer's own construction
Inlet Galvanized Belt Conveyor 1.To transport the raw material into drum dryer. 2. It is used to transport the wet sawdust to the rotary drum dryer, optional according to customer needs. 3.. If customer digs a pit, you will need belt conveyor with 50cm width and 10 meters length. If customer does not dig a pit, you will need belt conveyor with 50cm width and 8 meters length. 4.The belt conveyor needs to be equipped with a frequency converter to achieve one-button simultaneous operation with the rotary drum dryer
	Air Lock 1.To prevent the outside air.It has wind locking effect 2.The feed pipe can be uniformly and continuously fed. 3. Ensure that the gas and solid in the pneumatic output tube are relatively stable, so that the pneumatic conveying can work normally 4. It can partition the upper and lower air pressure of the discharger and play the role of gas lock
Fire Retardant Triplet 1. The mixing chamber can be separated from the furnace to extend the combustion time of fuel and volatiles and make the combustion more complete 2. Control the direction of the flame to prevent the high-temperature smoke from directly washing the dryer and burning the cylinder. 3. Prevent fire source from entering the inside of the drum dryer to ensure safe operation of the machine
	Cyclone 1. Also called cyclone dust collector, it is a kind of dust removal device. 2. Make the dusty air flow rotate, separate the dust particles from the air flow and trap them in the wall by means of centrifugal force, and then make the dust particles fall into the ash hopper by means of gravity. 3. No mechanical moving parts inside, easy to use and maintainTo collection Dust and discharge
Blower 1. Make the material subject to uniform heating, accelerate the evaporation rate of water in the material. 2. Exhaust the hot and humid gas from the drying chamber to reasonably control the temperature and humidity in the drying cylinder 3. Accelerate the evaporation rate of water in the material and improve the drying efficiency. 4.Reduce the waste of energy and reduce the energy consumption of the dryer operation.
	Electrical Cabinets 1. Power distribution cabinet we use well-known Chinese brand electrical components, we can also choose Schneider, Siemens electrical appliances according to customer requirements. Please contact Tony for price difference. 2.TONY granule machine has a one-click start function, to prevent customers do not know the start order and misoperation damage to the machine. 3 If the customer chooses a variable frequency motor, all components in the electric control cabinet need to use variable frequency control. Please contact Tony for the price difference of the inverter control cabinet

1.Strong overload resistance, large processing capacity, less fuel consumption, low drying cost;

2.Tthe use of downstream drying method, hot air and wet material from the same side into the dryer, you can use high temperature air to obtain high evaporation strength, the dryer outlet temperature is low, high thermal efficiency;

3. The operation parameters can be changed according to different material properties, so that the material can form a stable completely broken fabric curtain in the cylinder body, and the mass and heat exchange are more adequate;

4.The use of new feeding, discharging device, to eliminate the feed blockage, discontinuity, uneven and return of materials and other phenomena, reduce the load of dust removal system;

5.Achieve "zero horizontal thrust", greatly reduce the wear of the retaining wheel, stable and reliable cylinder operation;

6.The use of "aligning wheel support device", so that the support wheel and rolling ring with linear contact forever, thus greatly reducing wear and power loss;

7.According to user requirements to control product moisture.

Dryer model selection, to consider a variety of factors, such as your raw materials, the initial moisture content of raw materials, the drying effect you want, your output, etc., of course, we will also customize processing according to the specific situation, please contact Tony for specific information, we will answer your questions in detail

The Temperature Of The Combustion Furnace:

The temperature is too high will shorten the service life of the inner cylinder of the dryer (the oxidation and deformation of the steel plate in the inner cylinder of the dryer, long-term dry burning will lead to the scrapping of the dryer), too low will make the water content of the dry material rise, the product grade is reduced, and even unqualified. Therefore, the combustion chamber temperature is generally held at 750-850 ° C.

Additionally,the temperature bump of the combustion chamber can be adjusted by increasing or decreasing the fuel and air volume. If the combustion chamber temperature is too high, the fuel or air volume should be reduced. On the contrary, the amount of coal intake and air blast will be increased.

Please contact TONY for detailed information.

Smoke Exhaust Temperature:

Smoke exhaust temperature refers to the flue gas temperature leaving the dryer, the temperature is too high will increase energy consumption, the cost rises, the dust collector bag burnt; If it is too low, the water content of the material will rise, and the condensation will be formed simply, which is not conducive to the operation of the subsequent dust collector, so the exhaust gas temperature is generally held at about 90 ° C.

The bump of the flue gas temperature can be adjusted by increasing or decreasing the amount of wet material entering the dryer. If the flue gas temperature is high, the amount of wet material entering the dryer can be increased. On the contrary, the amount of wet material entering the dryer should be reduced

Please contact TONY for detailed information.

For the Dust Removal part of the dryer section, customers can choose cloth bag Dust Collector or Galvanized Pulsed Dust Collector, Water Spray Dust Removal according to their budget, production capacity, workshop area and other specific circumstances. Wet Electrostatic Precipitator.Please contact tony for specific price difference and parameters

Bag Dust Collector

Galvanized Pulsed Dust Collector

Water Spray Dust Removal

Wet Electrostatic Precipitator

1.Suitable for dealing with moderate air volume, low dust concentration occasions.

2.Simple structure,Physical filtration.

3.The maintenance is complicated, and the bag needs to be cleaned regularly.

4.High dust removal resistance.

1.It is more suitable for dealing with large air volume, high dust concentration and complex dust properties.

2.Automatic clearance mechanism.

3.Galvanized material, not easy to corrosion damage.

4.Limited by the temperature of the gas.

1.Water Spray Dust Removal is suitable for high pressure and cooling process

2. Small resistance, easy to operate

3. Slightly larger volume

4. Large water consumption, power consumption

1. Wet Electrostatic Precipitatoris the use of ionization effect

2. Steel structure is not easy to damage

3. Suitable for large-scale projects, the larger the amount of gas treated, the more obvious its economic role

4.High installation accuracy is required

Advantages: cost saving

Disadvantages:

1.The sawdust is stacked on the ground, and the dust flying affects the production environment of the workshop.

2. It is easy to spread on the ground and covers a large area.

3.More manual processing of sawdust is needed.

4. Sawdust stacked in the workshop, easy to lead to inconvenient traffic in the workshop.

5. Moisture or other factors in the workshop will affect the properties of sawdust and will affect the effect of granulation.

Advantages:

1 Large storage capacity, saving workshop area.

2. Improve the cleanliness of the workshop environment.

3. Save laborDisadvantages: Need to buy, high cost,High costspecific parameters and quotation please contact tony.

Ordinary Sawdust Auger Silo

1.The storage capacity is 5-30 square.

2. Compared with large hydraulic storage silo, it may be more prone to clogging or sticking.

Large Hydraulic Storage Silo

1.Storage capacity 40-300 square, more than most will not block material.

2.Galvanized material, not easy to corrode, durable, longer service life.

1.Crushing: Raw biomass materials, like wood or straw, are chipped into smaller pieces.

2.Further Crushing: These pieces go through another round of crushing for size uniformity, aiding in blending.

3.Drying: The crushed material is dried to reduce its moisture content to roughly 10-15%.

4.Pelleting: The dry material is pressed at high temperatures to create dense pellets.

5.Cooling: Freshly-made pellets are cooled down to harden.

6.Packaging: Finally, pellets are packed for transport and storage, in either small or bulk quantities.
