Wood pellet machine is a new type of environmental protection energy equipment, because the future trend of economic development will be around low-carbon environmental protection to start, after all, only environmental protection economy can long-term development and growth, and wood pellet machine is to save energy, reduce environmental pollution and was born, but when we encounter inevitable situations in the use of it will be disassembled, So what is the disassembly sequence of the wood pellet machine?
1. When the equipment is in production, if the operator finds that the current of the main machine is too large or the temperature of the granulation bin is too high, the operator should check whether the gap between the press roll and the ring die changes or whether the gap between the press roll and the ring die increases. If any abnormality is found, the maintenance worker should be informed to adjust the gap between the press roll or the gap between the press roll and the ring die.
2. After the maintenance worker repairs the press roll with too large gap, the press roll gap can be adjusted to meet the production requirements if no other abnormal circumstances are found.
3. To prepare for assembly when disassembly, in order to improve assembly efficiency and ensure the correctness of assembly, attention should be paid to check and mark when disassembly.
4. The dirt and oil on the surface should be removed before disassembly, and should be kept clean during disassembly.
5. Disassemble as needed, as little as possible, and do not disassemble those that are not allowed to be disassembled.
6. Use suitable tools when disassembling, and do not hit hard to avoid damage or deformation of parts.
7. Carefully check the removed roller parts and find that the parts that cannot be used should be replaced in time.
8. Clean the spare parts with diesel oil, clean them again with clean diesel oil, wipe them clean with cotton cloth, and put them in clean plastic bags or other clean flat objects for use.
9. On the disassembly device, press the bearing outer ring into the fixed position in the press roller shell, and then put the bearing inner ring into it, add the high-temperature lubricating oil, and install the other bearing in the same way.
10. Install high temperature oil seal and circlip.
11. Install the ash lid.
12. Adjust the gap of the press roll. When the gap is considered appropriate and the operation is flexible, fix the compression nut and fix the circlip blade to fix the gap of the press roll.
Before we carry out this disassembly work on the wood pellet machine, we also need to have a detailed understanding of the instructions and explanatory principles of the equipment, because it is very important to master the correct disassembly sequence of the equipment, so as not to disassemble randomly, causing various kinds of mechanical failures.
